Product


A、Automation Equipment for Semiconductor

   Probe Card Assembly Line



A-1 Automatic Probe Shaping & Inspection Machine

   -- Automatic probe feeding and discharging system
   -- Automatic probe bending and dimension angle measurement
   -- Automatic probe cutting and dimension measurement
   -- High-precision AOI image measurement system
   -- Software/algorithm/AOI/mechanism/electronic control are all      proprietary technologies with high problem-solving capabilities







A-2 Automatic Probe Fixed & Inspection Machine

   -- Automatic probe feeding system
   -- High-precision six-axis module for probe placement,
     high-precision dispensing and curing module
   -- Automatic EXPOXY coating and baking
   -- Needle position inspection and measurement
   -- Software/algorithm/AOI/mechanism/electronic control are all      proprietary technologies with high problem-solving capabilities







A-3 Automatic Probe Grinding & Inspection Machine

   -- High/low magnification visual system, fast probe card inspection      settings
   -- Can record the setting information of different ProbeCards
   -- With height measurement and anti-collision mechanism
   -- Probe inspection includes needle position, needle diameter, needle      length...
   -- Can be customized to add probe grinding and reliability testing      functions
   -- Software/algorithm/AOI/mechanism/electronic control are all      proprietary technologies with high problem-solving capabilities







A-4 Automatic Probe tip Inspection & Adjustment Machine

   -- High-precision optical scale and granite platform for optimal      measurement reproducibility
   -- Leica optical system relieves operator stress
   -- Graphical UI allows operators to intuitively move to offset needle      positions for needle adjustment
   -- Industrial hand wheel for easy position adjustment
   -- Software/algorithms/AOI/mechanisms/electronic controls are all      proprietary technologies with high problem-solving capabilities







A-5 Automatic Probe Insertion Machine

   -- Continuous insertion 6000 pcs/day
   -- Support round needles/square needles
   -- Assembly position visual recognition system
   -- Probe tip visual recognition system
   -- Probe feeding and assembly system
   -- Real-time thrust detection system
   -- Probe transfer transmission system
